Mavic Ksyrium SL Disc Rear Wheel

The Mavic Ksyrium SL Disc rear wheel embodies the excellence of French craftsmanship in premium aluminum wheels for road cycling. Lighter than ever thanks to patented ISM4D machining, it combines exceptional lateral stiffness, maximum durability, and ultra-precise disc braking. Featuring Fore technology with no rim tape and the UST Tubeless system, this rear wheel is the ultimate choice for demanding cyclists seeking everyday performance, speed, and comfort.

Mavic Ksyrium SL Disc rear wheel highlights

• Patented ISM4D machining: Removes excess material between the spoke holes, reducing rim weight to just 400 g and drastically lowering rotational inertia.
• Fore technology (tubeless, no rim tape): The rim’s upper bridge remains intact, increasing stiffness by 20% while saving 30 g of rim tape per wheel.
• Patented aerodynamic spokes: Exclusive elliptical-profile bladed spokes help save up to 5 watts of rolling resistance.
• Infinity hub & ID360 freehub: Instant power transfer (9° engagement) thanks to the Instant Drive 360 dual-pawl system and non-contact spoke lacing.
• UST Road Tubeless system: Easy, airtight tubeless setup provides more traction and comfort, along with greatly improved puncture resistance.
• QRM Auto bearings: Sealed cartridge bearings with automatic preload adjustment for smooth, durable rotation with no mechanical play.

Technical specifications

• Position: Rear.
• Riding style: Endurance road, racing, sportive (ASTM Category 2).
• Rim material: Maxtal aluminum alloy (Made in France).
• Rim height: 22 mm.
• Internal width: 19 mm (ETRTO 622x19TC, hooked profile).
• Rim drilling / spoke holes: Fore technology (24 holes, no drilling through the upper bridge).
• Freehub technology: Instant Drive 360 (ID360, 9° engagement / 40 teeth).
• Freehub body: Shimano and SRAM HG Road / SRAM XDR / Campagnolo optional with a freehub body replacement
• Rotor mount: Center Lock® only.
• Thru-axle: 12x142 mm (convertible to QR 9x135 mm quick release with adapters).
• Spoke type: 24 straight, bladed, butted, anti-rotation stainless steel spokes (2-cross).

Construction and materials

• Rim: 100% Maxtal aluminum alloy (machined SUP weld)
• Spokes: 100% stainless steel (M7 brass nipples)
• Hub: Aluminum body and axle (Infinity design)
• Bearings: Sealed cartridge (QRM Auto technology)

Maintenance tips

• Clean the wheel with fresh water and a sponge or soft cloth (avoid using a pressure washer directly on the bearings and freehub).
• Check and replace the tubeless sealant regularly (every 3 to 6 months).
• Lubricate the ID360 freehub mechanism only with the dedicated Mavic grease.

Compatibility, tires, and installation

For optimal performance and safety on the road, follow the specifications and usage limits recommended by Mavic.

• Recommended tire width: 23 mm to 32 mm road tires (minimum width: 23 mm).
• Tire type: UST Tubeless Ready or Tube Type (with an inner tube).
• Inflation pressure: Maximum pressure of 6.75 Bar / 97 PSI (with a 23 mm tire).
• Freehub compatibility: Original Shimano HG or SRAM XDR (convertible to Campagnolo with optional freehub bodies).
• Weight limit: Maximum supported weight for the wheels: 120 kg (including the bike).

Package contents and tubeless setup

• Included accessories: User guide, UST valve (not installed), and multifunction adjustment wrench.
• Fore Tubeless advantage: No rim tape required for an airtight seal. Install the UST valve, fit your Tubeless Ready tire, and add sealant.
